Pictures for Yamaha YZ250F 2004
Yamaha 2004 YZ250F Specs:
ENGINE: Liquid-cooled, 5-valve, DOHC, 4-stroke w/titanium valves
DISPLACEMENT: 249cc
BORE X STROKE: 77 x 53.6mm
COMPRESSION RATIO: 12.5:1
CARBURETION: 37mm Keihin FCR flat-slide w/throttle position sensor
CLUTCH: Multi-plate wet clutch
IGNITION: Digital CDI
DIMENSIONS
LENGTH: 85.1 in.
WIDTH: 32.6 in.
HEIGHT: 51.3 in.
WEIGHT: 208 lbs.
GROUND CLEARANCE: 15.0 in.
WHEELBASE: 58.0 in.
FUEL CAPACITY: 1.8 gal.
SEAT HEIGHT: 39.2 in.
DRIVETRAIN
TRANSMISSION: 5-speed
FINAL DRIVE: #520 chain
SUSPENSION: Front: 48mm Kayaba inverted cartridge fork w/adj. compression & rebound damping; 11.8 in. travel
Rear: Kayaba single shock w/adj. preload, compression & rebound damping & separate hi/lo-speed compression adjuster; 12.4 in. travel
BRAKES/WHEELS/TIRES
BRAKES Front: 250mm floating disc
Rear: 245mm disc
TIRES Front: 80/100-21 Dunlop
Rear: 100/90-19 Dunlop
ENGINE: Liquid-cooled, 5-valve, DOHC, 4-stroke w/titanium valves
DISPLACEMENT: 249cc
BORE X STROKE: 77 x 53.6mm
COMPRESSION RATIO: 12.5:1
CARBURETION: 37mm Keihin FCR flat-slide w/throttle position sensor
CLUTCH: Multi-plate wet clutch
IGNITION: Digital CDI
DIMENSIONS
LENGTH: 85.1 in.
WIDTH: 32.6 in.
HEIGHT: 51.3 in.
WEIGHT: 208 lbs.
GROUND CLEARANCE: 15.0 in.
WHEELBASE: 58.0 in.
FUEL CAPACITY: 1.8 gal.
SEAT HEIGHT: 39.2 in.
DRIVETRAIN
TRANSMISSION: 5-speed
FINAL DRIVE: #520 chain
SUSPENSION: Front: 48mm Kayaba inverted cartridge fork w/adj. compression & rebound damping; 11.8 in. travel
Rear: Kayaba single shock w/adj. preload, compression & rebound damping & separate hi/lo-speed compression adjuster; 12.4 in. travel
BRAKES/WHEELS/TIRES
BRAKES Front: 250mm floating disc
Rear: 245mm disc
TIRES Front: 80/100-21 Dunlop
Rear: 100/90-19 Dunlop
