Yamaha YZ360, YZ400, YZ465, YZ490, WR500 ENGINE, PARTS, AND FRAME Identification page
In an effort to help fellow bikers properly ID their bike I have provided the following information on VIN ( Vehicle Identification Number ) , Engine ID and part identification.
All the information provided is to the best of my knowledge correct.
As we part more bikes out we will add more information to this chart.
If you find something that is not accurate, please let us know and we will fix it.
This information is not intended for use outside of this web site or for publication.
In other words, use this information at your own risk.
Please scroll to the right as there is a lot of data :-)
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
| 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 34mm x 46mm x 10.5 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 74-77 YZ250, 74-75 YZ360, 76-77 YZ400, 75 MX250, 75 MX400, 76 IT400, 76-78 TT500, 431-25381-00-00 | 1974 | YZ360 | 1974 | YZ360 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1974 | YZ360 | 1974 | YZ360 | FITS 74-78 YZ250, 74-75 YZ360, 76-77 YZ400, 77-78 IT250, 76-78 IT400, 75 MX250 MX400 - 431-13610-01-00 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | 1974 | YZ360 | ||||||||||||||||||||||||||||||||||||||||||||||||
| 1975 | YZ360 | 484-000101 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 34mm x 46mm x 10.5 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 74-77 YZ250, 74-75 YZ360, 76-77 YZ400, 75 MX250, 75 MX400, 76 IT400, 76-78 TT500, 431-25381-00-00 | 1975 | YZ360 | 1975 | YZ360 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1975 | YZ360 | 1975 | YZ360 | FITS 74-78 YZ250, 74-75 YZ360, 76-77 YZ400, 77-78 IT250, 76-78 IT400, 75 MX250 MX400 - 431-13610-01-00 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | 1975 | YZ360 | |||||||||||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
| 1976 | YZ400 | 510-100101 | 1976 | YZ400 | FITS 75 MX250 MX400, 76 IT400 YZ250 YZ400 - 510-13555-02-00 | 1976 | YZ400 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | 1976 | YZ400 | 1976 | YZ400 | FITS 76-78 YZ400, 77-78 IT250 & IT400 | FITS 76-78 YZ400 | 1976 | YZ400 | 1976 | YZ400 | FITS 76-79 YZ250 & YZ400 | 1976 | YZ400 | FITS 76-81 YZ250, 76-79 YZ400, 77-84 YZ125, 77-83 IT175, 77-82 IT250, 77-79 IT400, 80 IT425, 80-82 TT250, 79-81 TT500, 84-85 IT200, 1W1-25016-11-98 | 1976 | YZ400 | 1976 | YZ400 | IK710 - DRUM ID 130MM - AXLE ID 15MM - BRG TO BRG 93-94MM - FITS 76-81 YZ250, 76-79 YZ400, 77-81 IT175 IT250 YZ125 , 77-79 IT400, 77 79 81 TT500, 77 YZ100 | 1976 | YZ400 | 74-77 YZ250, 74-75 YZ360, 76-77 YZ400, 75 MX250, 75 MX400, 76 IT400, 76-78 TT500, 431-25381-00-00 | 1976 | YZ400 | FITS 75 MX250 MX400 YZ360, 75-76 YZ250, 76 IT400, YZ400, 76-78 TT500. 483-25321-00-98 | 1976 | YZ400 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1976 | YZ400 | 1976 | YZ400 | FITS 74-78 YZ250, 74-75 YZ360, 76-77 YZ400, 77-78 IT250, 76-78 IT400, 75 MX250 MX400 - 431-13610-01-00 | FITS 76 YZ400 | 1976 | YZ400 | 1976 | YZ400 | 1976 | YZ400 | 1976 | YZ400 | |||||||||||||||||||||||||||||||||||||||
| 1977 | YZ400 | 1W4-000101 | FITS 77-78 YZ400 | 1977 | YZ400 | FITS 77-79 YZ125 YZ400, 77-80 YZ250, 80 YZ465 | 1W4 FITS 77-78 YZ400 YZ250 | 1W4 - 70.5MM X 52MM BP - TANG 53.5MM X 30.5MM -FITS 77-78 YZ400 IT400 IT250 | 1977 | YZ400 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | FITS 77-89 IT250, IT400, YZ250, YZ400 | 1977 | YZ400 | 1977 | YZ400 | FITS 76-78 YZ400, 77-78 IT250 & IT400 | FITS 76-78 YZ400 | 1977 | YZ400 | F3T351 OR F3T350 FITS 77-78 80 IT250, 77-78 IT400, 77 YZ400 1W4-85550-20-00 | 1977 | YZ400 | CONVENTIONAL - KYB - 38MM CHROME OD - C/L 33 7/8" - AXLE HOLES 20MM & 15MM - FITS 77-78 YZ400, 77-79 YZ250, 80 YZ465 | 38mm x 50mm x 8 | FITS 76-79 YZ250 & YZ400 | 1977 | YZ400 | FITS 76-81 YZ250, 76-79 YZ400, 77-84 YZ125, 77-83 IT175, 77-82 IT250, 77-79 IT400, 80 IT425, 80-82 TT250, 79-81 TT500, 84-85 IT200, 1W1-25016-11-98 | 1977 | YZ400 | 1977 | YZ400 | IK710 - DRUM ID 130MM - AXLE ID 15MM - BRG TO BRG 93-94MM - FITS 76-81 YZ250, 76-79 YZ400, 77-81 IT175 IT250 YZ125 , 77-79 IT400, 77 79 81 TT500, 77 YZ100 | 1977 | YZ400 | 74-77 YZ250, 74-75 YZ360, 76-77 YZ400, 75 MX250, 75 MX400, 76 IT400, 76-78 TT500, 431-25381-00-00 | 1977 | YZ400 | FITS 77-78 YZ400 YZ250, 79 & 81 TT500 | 1977 | YZ400 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1977 | YZ400 | 2.15X18 FITS 74-79 YZ250, 74-75 YZ360, 75 MX250 MX400, 76-77 79 81 TT500, 77-80 IT250, 77-78 YZ400 IT400, 80 IT425 | 1977 | YZ400 | FITS 74-78 YZ250, 74-75 YZ360, 76-77 YZ400, 77-78 IT250, 76-78 IT400, 75 MX250 MX400 - 431-13610-01-00 | FITS 77-78 YZ250 & YZ400 - NOT 76 | 1977 | YZ400 | 1977 | YZ400 | FITS 77-79 YZ125, 77-80 YZ250, 77-79 YZ400, 80 YZ465 | 1977 | YZ400 | 1977 | YZ400 | ||||||||||||||||||||||||||||||
| 1978 | YZ400 | 2K8-000101 | FITS 77-78 YZ400 | 1978 | YZ400 | FITS 77-79 YZ125 YZ400, 77-80 YZ250, 80 YZ465 | 1W4 FITS 77-78 YZ400 YZ250 | 1W4 - 70.5MM X 52MM BP - TANG 53.5MM X 30.5MM -FITS 77-78 YZ400 IT400 IT250 | 1978 | YZ400 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | FITS 77-89 IT250, IT400, YZ250, YZ400 | 1978 | YZ400 | 1978 | YZ400 | FITS 76-78 YZ400, 77-78 IT250 & IT400 | FITS 76-78 YZ400 | 1978 | YZ400 | 1978 | YZ400 | CONVENTIONAL - KYB - 38MM CHROME OD - C/L 33 7/8" - AXLE HOLES 20MM & 15MM - FITS 77-78 YZ400, 77-79 YZ250, 80 YZ465 | 38mm x 50mm x 8 | FITS 76-79 YZ250 & YZ400 | 1978 | YZ400 | FITS 76-81 YZ250, 76-79 YZ400, 77-84 YZ125, 77-83 IT175, 77-82 IT250, 77-79 IT400, 80 IT425, 80-82 TT250, 79-81 TT500, 84-85 IT200, 1W1-25016-11-98 | 1978 | YZ400 | 1978 | YZ400 | IK710 - DRUM ID 130MM - AXLE ID 15MM - BRG TO BRG 93-94MM - FITS 76-81 YZ250, 76-79 YZ400, 77-81 IT175 IT250 YZ125 , 77-79 IT400, 77 79 81 TT500, 77 YZ100 | 1978 | YZ400 | 1978 | YZ400 | FITS 77-78 YZ400 YZ250, 79 & 81 TT500 | 1978 | YZ400 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1978 | YZ400 | 2.15X18 FITS 74-79 YZ250, 74-75 YZ360, 75 MX250 MX400, 76-77 79 81 TT500, 77-80 IT250, 77-78 YZ400 IT400, 80 IT425 | 1978 | YZ400 | FITS 74-78 YZ250, 74-75 YZ360, 76-77 YZ400, 77-78 IT250, 76-78 IT400, 75 MX250 MX400 - 431-13610-01-00 | FITS 77-78 YZ250 & YZ400 - NOT 76 | 1978 | YZ400 | 1978 | YZ400 | FITS 77-79 YZ125, 77-80 YZ250, 77-79 YZ400, 80 YZ465 | 1978 | YZ400 | 1978 | YZ400 | CLICK HERE FOR MEASUREMENTS YZ400 1978 SWING ARM | |||||||||||||||||||||||||||||||
| 1979 | YZ400 | 2X5-000101 | 1979 | YZ400 | FITS 77-79 YZ125 YZ400, 77-80 YZ250, 80 YZ465 | 1979 | YZ400 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | 1979 | YZ400 | 1979 | YZ400 | 82MM STANDARD BORE | 1979 | YZ400 | 1979 | YZ400 | 38mm x 50mm x 8 | FITS 76-79 YZ250 & YZ400 | 1979 | YZ400 | FITS 76-81 YZ250, 76-79 YZ400, 77-84 YZ125, 77-83 IT175, 77-82 IT250, 77-79 IT400, 80 IT425, 80-82 TT250, 79-81 TT500, 84-85 IT200, 1W1-25016-11-98 | 1979 | YZ400 | 1979 | YZ400 | IK710 - DRUM ID 130MM - AXLE ID 15MM - BRG TO BRG 93-94MM - FITS 76-81 YZ250, 76-79 YZ400, 77-81 IT175 IT250 YZ125 , 77-79 IT400, 77 79 81 TT500, 77 YZ100 | 1979 | YZ400 | FITS 78-79 YZ250, 79 YZ400, 79-80 IT250, 79 IT400, 80 IT425 - 2K7-15661-01-00 | 2X500 ART 1/2 81025 | 1979 | YZ400 | FITS 79 YZ250, YZ400, 1980 YZ465 | 1979 | YZ400 | 483 - AXLE ID 17MM - BRG TO BRG 126MM - HUB ID 160MM – SPROCKET BC 6X 164MM – FITS 74-79 YZ250, 74-75 YZ360, 75 MX250, 75 MX400, 76-79 & 81 TT500, 76-79 YZ400, 77-80 IT250, 77-79 IT400, 80 IT425 | 1979 | YZ400 | 1979 | YZ400 | FITS 80-81 YZ250, 79 YZ400 IT400, 79-82 IT250, 80 IT425 - 2X5-13610-00-00 | FITS 79 YZ250 & YZ400 - 2X4-W2473-00-00 | 1979 | YZ400 | 1979 | YZ400 | FITS 77-79 YZ125, 77-80 YZ250, 77-79 YZ400, 80 YZ465 | 1979 | YZ400 | 1979 | YZ400 | |||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
| 1980 | YZ465 | 3R5-000101 | FITS 80 YZ250 & YZ465 | 1980 | YZ465 | FITS 77-79 YZ125 YZ400, 77-80 YZ250, 80 YZ465 | 1980 | YZ465 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | Fits 80-82 YZ250, 80-81 YZ465, 81-82 IT250, 81-82 IT465 | 1980 | YZ465 | 1980 | YZ465 | 1980 | YZ465 | 1980 | YZ465 | CONVENTIONAL - KYB - 38MM CHROME OD - C/L 33 7/8" - AXLE HOLES 20MM & 15MM - FITS 77-78 YZ400, 77-79 YZ250, 80 YZ465 | 38mm x 50mm x 8 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1980 | YZ465 | 1980 | YZ465 | 1980 | YZ465 | 1980 | YZ465 | FITS 80-87 YZ250, 80-81 YZ465, 82 YZ490, 81-82 IT250 IT465 - 56A-15661-01-00 | 1980 | YZ465 | FITS 79 YZ250, YZ400, 1980 YZ465 | 1980 | YZ465 | 1980 | YZ465 | 1980 | YZ465 | FITS 80-82 YZ250, 80-81 YZ465, 82 YZ490, 80-81 IT175, 81-83 IT250, 81-82 IT465, 82-84 IT490 | 1980 | YZ465 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1980 | YZ465 | FITS 77-79 YZ125, 77-80 YZ250, 77-79 YZ400, 80 YZ465 | 1980 | YZ465 | 1980 | YZ465 | |||||||||||||||||||||||||||||||||||||||
| 1981 | YZ465 | 4V4-000101 | FITS 81 YZ250 & YZ465 | 1981 | YZ465 | 1981 | YZ465 | F8T00 FITS 75-78 DT400, 75 MX400, 76-79 YZ400, 80-81 YZ465, 77-79 IT 400, 80 IT425, 81-82 IT465 | Fits 80-82 YZ250, 80-81 YZ465, 81-82 IT250, 81-82 IT465 | 1981 | YZ465 | 1981 | YZ465 | 1981 | YZ465 | 1981 | YZ465 | CONVENTIONAL - 43MM CHROME OD | 43mm x 55mm x 9.5/10.5/11 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1981 | YZ465 | 1981 | YZ465 | 1981 | YZ465 | 1981 | YZ465 | FITS 80-87 YZ250, 80-81 YZ465, 82 YZ490, 81-82 IT250 IT465 - 56A-15661-01-00 | 1981 | YZ465 | FITS 81 YZ250 AND YZ 465 | 1981 | YZ465 | 20MM AXLE - BRG TO BRG 132MM - DRUM ID 150MM - FITS 81-83 IT250, 81-82 IT465, 83-84 IT490, 81 YZ250, 81 YZ465, 82 YZ490 | 1981 | YZ465 | 1981 | YZ465 | FITS 80-82 YZ250, 80-81 YZ465, 82 YZ490, 80-81 IT175, 81-83 IT250, 81-82 IT465, 82-84 IT490 | 1981 | YZ465 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1981 | YZ465 | 1981 | YZ465 | TRIPLE TREE FITS 81 YZ465 & 82 YZ490 | 1981 | YZ465 | |||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
| 1982 | YZ490 | 5X6-000101 | FITS 82 YZ490 YZ250 5X5-26335-01-00 | FITS 82-84 YZ490, 83-84 YZ125, 83 YZ250 5X6-26341-00-00 | 1982 | YZ490 | 1982 | YZ490 | 1982 | YZ490 | 1982 | YZ490 | FITS 82 YZ490 ONLY – 5X6-11311-00-00 – 87MM STD BORE | 1982 | YZ490 | F3T201 | 1982 | YZ490 | CONVENTIONAL - 43MM CHROME OD - C/L 36" - AXLE HOLES 20MM & 15MM - FITS 82 YZ490 & YZ250 | 43mm x 55mm x 9.5/10.5/11 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1982 | YZ490 | FITS 82-84 YZ250 & 490, 83 IT250, 83-84 IT490, 83-84 TT600 - 5X6-25121-00-98 | 1982 | YZ490 | 1982 | YZ490 | 130MM DRUM DIA | FITS 82 YZ490 5X6-11111-00-00 | 1982 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465, 82 YZ490, 81-82 IT250 IT465 - 56A-15661-01-00 | 1982 | YZ490 | FITS 82- YZ250 & YZ490 – 5X5-25371-00-00 – EYE TO EYE 21 1/8” | 1982 | YZ490 | 20MM AXLE - BRG TO BRG 132MM - DRUM ID 150MM - FITS 81-83 IT250, 81-82 IT465, 83-84 IT490, 81 YZ250, 81 YZ465, 82 YZ490 | 1982 | YZ490 | 1982 | YZ490 | FITS 80-82 YZ250, 80-81 YZ465, 82 YZ490, 80-81 IT175, 81-83 IT250, 81-82 IT465, 82-84 IT490 | 1982 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1982 | YZ490 | FITS 82-85 YZ250 YZ490, 83 IT250, 83-84 IT490 5X6-22141-01-00 | 1982 | YZ490 | TRIPLE TREE FITS 81 YZ465 & 82 YZ490 | 1982 | YZ490 | ||||||||||||||||||||||||||||||||||
| 1983 | YZ490 | 23X-000101 | FITS 82-84 YZ490, 83-84 YZ125, 83 YZ250 5X6-26341-00-00 | 1983 | YZ490 | FITS 83 YZ490 ONLY | 1983 | YZ490 | 23X-20 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1983 | YZ490 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1983 | YZ490 | F6T411 | FITS 83 YZ490 ONLY - 23X-11311-00-00 – 87MM STD BORE | 1983 | YZ490 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1983 | YZ490 | CONVENTIONAL – KYB - 43MM CHROME OD - C/L 36" - AXLE HOLES 20MM & 15MM | 43mm x 55mm x 9.5/10.5/11 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1983 | YZ490 | FITS 82-84 YZ250 & 490, 83 IT250, 83-84 IT490, 83-84 TT600 - 5X6-25121-00-98 | 1983 | YZ490 | 1983 | YZ490 | 23X00 15MM AXLE DIA - BRG TO BRG 94MM - FITS 82-84 YZ250 & 125, 82 IT465, 82 TT250, 82 IT175, 83-84 TT600, 83 YZ490 | FITS 1983 YZ490 23X-11111-00-00 | 1983 | YZ490 | 1983 | YZ490 | FITS 83-87 YZ250, 87 YZ125, 83 YZ490 | 1983 | YZ490 | 1983 | YZ490 | 23X-00 2-A FITS 83 IT250 YZ490, 83-84 IT490, 83-84 YZ250 | 1983 | YZ490 | 1983 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1983 | YZ490 | FITS 82-85 YZ250 YZ490, 83 IT250, 83-84 IT490 5X6-22141-01-00 | 1983 | YZ490 | 1983 | YZ490 | ||||||||||||||||||||||||||||||||
| 1984 | YZ490 | 40T-000101 | FITS 83-85 YZ250, 84-85 YZ490 | FITS 82-84 YZ490, 83-84 YZ125, 83 YZ250 5X6-26341-00-00 | 1984 | YZ490 | 1984 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1984 | YZ490 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1984 | YZ490 | FITS 84-86 YZ490 – 40T-11311-02-00 – 87MM STD | 1984 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | FITS 84-85 YZ250 ONLY | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1984 | YZ490 | 43MM CHROME OD | 43mm x 55mm x 9.5/10.5/11 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1984 | YZ490 | FITS 82-84 YZ250 & 490, 83 IT250, 83-84 IT490, 83-84 TT600 - 5X6-25121-00-98 | 1984 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1984 | YZ490 | FITS 84-90 YZ490 40T-11111-00-00 | 1984 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1984 | YZ490 | FITS 84-90 YZ490 | 1984 | YZ490 | 1984 | YZ490 | 1984 | YZ490 | 23X 82.5 Fits 83-85 YZ250 & 84-85 YZ490 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1984 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1984 | YZ490 | FITS 82-85 YZ250 YZ490, 83 IT250, 83-84 IT490 5X6-22141-01-00 | 1984 | YZ490 | 1984 | YZ490 | ||||||||||||||||||||||||||||||
| 1985 | YZ490 | 57H-00 | FITS 83-85 YZ250, 84-85 YZ490 | 1985 | YZ490 | 1985 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1985 | YZ490 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1985 | YZ490 | FITS 84-86 YZ490 – 40T-11311-02-00 – 87MM STD | 1985 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | FITS 84-85 YZ250 ONLY | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1985 | YZ490 | 43MM CHROME OD | 43mm x 55mm x 9.5/10.5/11 | FITS 80-85 YZ250, 80-81 YZ465, 82-85 YZ125 & YZ490 – 3R4-25181-01-00 | 1985 | YZ490 | 1985 | YZ490 | 240MM OD - ID 117.5MM - BOLTS 4 ON BC ON 130MM - FITS 85 YZ125, 250, 490 | FITS 84-90 YZ490 & 92-93 WR500 | 1985 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | FITS 84-90 YZ490 40T-11111-00-00 | 1985 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1985 | YZ490 | FITS 84-90 YZ490 | 1985 | YZ490 | 1985 | YZ490 | 1985 | YZ490 | 23X 82.5 Fits 83-85 YZ250 & 84-85 YZ490 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1985 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1985 | YZ490 | FITS 82-85 YZ250 YZ490, 83 IT250, 83-84 IT490 5X6-22141-01-00 | 1985 | YZ490 | 1985 | YZ490 | ||||||||||||||||||||||||||||||
| 1986 | YZ490 | 1LV-00 | FITS 86 YZ125 YZ490 - 1LX-W1441-01-00 | FITS 86 YZ125 YZ490 - 1LX-14458-00-00 | FITS 86 YZ490 - 1LV-14453-00-00 | 1986 | YZ490 | 1LV | 1986 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1986 | YZ490 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1986 | YZ490 | FITS 84-86 YZ490 – 40T-11311-02-00 – 87MM STD | 1986 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1986 | YZ490 | CONVENTIONAL - KAYABA - YILX-R YILX-L - 43MM CHROME OD - 36 1/4" C/L - BRAKE MOUNT C/L 85MM - AXLE HOLES 20MM & 15MM - FITS 86 YZ490 | 43mm x 55mm x 9.5/10.5/11 | FITS 86-91 YZ125 YZ250, 86-90 YZ490, ANY MANY OTHERS | 1986 | YZ490 | 1986 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1986 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | FITS 84-90 YZ490 40T-11111-00-00 | 1986 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1986 | YZ490 | FITS 84-90 YZ490 | 1986 | YZ490 | FITS 86-90 YZ125 YZ250 YZ490 - 1LX-21611-00-00 | 1986 | YZ490 | FITS 86-90 YZ490, 86 YZ125, 87 YZ250 | 1986 | YZ490 | 5X6 – FITS 86-88 YZ125, YZ250, YZ490 1LX-24770-10-00 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1986 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | FITS 77-87 YZ250, 79-83 IT250, 85-86 TY350, 86 YZ490 146.88mm | 1986 | YZ490 | LEFT 1LX-21711-01-98 - FITS 86-88 YZ125, 86-87 YZ250, 86-90 YZ490 | RIGHT - 99999-01787-00 - FITS 86-87 YZ125 YZ250 YZ490 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1986 | YZ490 | FITS 86-90 YZ490 & 92-93 WR500 | 1986 | YZ490 | ||||||||||||||||||||||
| 1987 | YZ490 | 2HJ-00 | FITS 87-88 YZ125, 86-87 YZ250, 87-90 YZ490 | 1987 | YZ490 | 1987 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1987 | YZ490 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1987 | YZ490 | FITS 87-90 YZ490 – 2HJ-11311-00-00 – 87MM STD BORE | 1987 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1987 | YZ490 | CONVENTIONAL - KAYABA -YILX-R YILX-L - 43MM CHROME OD - 36 1/4" C/L - BRAKE MOUNT C/L 85MM - AXLE HOLES 20MM & 15MM - FITS 87 YZ250 & 490 | 43mm x 55mm x 9.5/10.5/11 | FITS 86-91 YZ125 YZ250, 86-90 YZ490, ANY MANY OTHERS | 1987 | YZ490 | 1987 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1987 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | 2HH00 - BLACK - 15MM AXLE DIA - BRG TO BRG 86.7MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - 36 SPOKES - FITS 87-89 YZ125, YZ250 & 87-90 YZ490 | FITS 84-90 YZ490 40T-11111-00-00 | 1987 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1987 | YZ490 | FITS 84-90 YZ490 | 1987 | YZ490 | FITS 86-90 YZ125 YZ250 YZ490 - 1LX-21611-00-00 | 1987 | YZ490 | FITS 86-90 YZ490, 86 YZ125, 87 YZ250 | 1987 | YZ490 | 5X6 – FITS 86-88 YZ125, YZ250, YZ490 1LX-24770-10-00 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1987 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | Spring thickness: 11.3MM OD - Spring Diameter: 84MM - Spring length as mounted: 254MM - Upper mount tab thickness: 27.1MM - Upper mount tab hole ID: 12MM - Lower mount Width: 25.1MM - Lower mount hole ID: 12MM - Eye to Eye: 425MM FITS 87 YZ490 & YZ250 | 1987 | YZ490 | LEFT 1LX-21711-01-98 - FITS 86-88 YZ125, 86-87 YZ250, 86-90 YZ490 | RIGHT - 99999-01787-00 - FITS 86-87 YZ125 YZ250 YZ490 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1987 | YZ490 | FITS 86-90 YZ490 & 92-93 WR500 | 1987 | YZ490 | |||||||||||||||||||||||||
| 1988 | YZ490 | 2HJ-00 | FITS 87-88 YZ125, 86-87 YZ250, 87-90 YZ490 | 1988 | YZ490 | 1988 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1988 | YZ490 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1988 | YZ490 | FITS 87-90 YZ490 – 2HJ-11311-00-00 – 87MM STD BORE | 1988 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1988 | YZ490 | 43mm x 55mm x 9.5/10.5/11 | FITS 86-91 YZ125 YZ250, 86-90 YZ490, ANY MANY OTHERS | 1988 | YZ490 | 1988 | YZ490 | OD 230MM - ID 86MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - FITS 85-86 TT600, TT350 - 86 IT200 - 88 YZ125, YZ250 - 88-90 YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1988 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | 2HH00 - BLACK - 15MM AXLE DIA - BRG TO BRG 86.7MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - 36 SPOKES - FITS 87-89 YZ125, YZ250 & 87-90 YZ490 | FITS 84-90 YZ490 40T-11111-00-00 | 1988 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1988 | YZ490 | FITS 84-90 YZ490 | 1988 | YZ490 | FITS 86-90 YZ125 YZ250 YZ490 - 1LX-21611-00-00 | 1988 | YZ490 | FITS 86-90 YZ490, 86 YZ125, 87 YZ250 | 1988 | YZ490 | 5X6 – FITS 86-88 YZ125, YZ250, YZ490 1LX-24770-10-00 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1988 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | FITS 88-90 YZ490 | 1988 | YZ490 | LEFT 1LX-21711-01-98 - FITS 86-88 YZ125, 86-87 YZ250, 86-90 YZ490 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1988 | YZ490 | FITS 86-90 YZ490 & 92-93 WR500 | 1988 | YZ490 | ||||||||||||||||||||||||||
| 1989 | YZ490 | 2HJ-00 | FITS 87-88 YZ125, 86-87 YZ250, 87-90 YZ490 | 1989 | YZ490 | 1989 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1989 | YZ490 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1989 | YZ490 | FITS 87-90 YZ490 – 2HJ-11311-00-00 – 87MM STD BORE | 1989 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1989 | YZ490 | 43mm x 55mm x 9.5/10.5/11 | FITS 86-91 YZ125 YZ250, 86-90 YZ490, ANY MANY OTHERS | 1989 | YZ490 | 1989 | YZ490 | OD 230MM - ID 86MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - FITS 85-86 TT600, TT350 - 86 IT200 - 88 YZ125, YZ250 - 88-90 YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1989 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | 2HH00 - BLACK - 15MM AXLE DIA - BRG TO BRG 86.7MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - 36 SPOKES - FITS 87-89 YZ125, YZ250 & 87-90 YZ490 | FITS 84-90 YZ490 40T-11111-00-00 | 1989 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1989 | YZ490 | FITS 84-90 YZ490 | 1989 | YZ490 | FITS 86-90 YZ125 YZ250 YZ490 - 1LX-21611-00-00 | 1989 | YZ490 | FITS 86-90 YZ490, 86 YZ125, 87 YZ250 | 1989 | YZ490 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1989 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | FITS 88-90 YZ490 | 1989 | YZ490 | LEFT 1LX-21711-01-98 - FITS 86-88 YZ125, 86-87 YZ250, 86-90 YZ490 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1989 | YZ490 | FITS 86-90 YZ490 & 92-93 WR500 | 1989 | YZ490 | |||||||||||||||||||||||||||
| 1990 | YZ490 | 2HJ-00 | FITS 87-88 YZ125, 86-87 YZ250, 87-90 YZ490 | 1990 | YZ490 | 1990 | YZ490 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1990 | YZ490 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1990 | YZ490 | FITS 87-90 YZ490 – 2HJ-11311-00-00 – 87MM STD BORE | 1990 | YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1990 | YZ490 | 43mm x 55mm x 9.5/10.5/11 | FITS 86-91 YZ125 YZ250, 86-90 YZ490, ANY MANY OTHERS | 1990 | YZ490 | 1990 | YZ490 | OD 230MM - ID 86MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - FITS 85-86 TT600, TT350 - 86 IT200 - 88 YZ125, YZ250 - 88-90 YZ490 | FITS 84-90 YZ490 & 92-93 WR500 | 1990 | YZ490 | FITS 85-90 YZ125 490, 85-88 YZ250, 80-81 IT250 IT175 IT250, 80 IT400, 81 IT465 - 5X6-21511-11-00 - 55MM C/L WIDTH, 65MM C/L LENGTH | 2HH00 - BLACK - 15MM AXLE DIA - BRG TO BRG 86.7MM - 6 BOLTS UNEQUAL SPACING ON A 102MM BOLT CIRCLE - 36 SPOKES - FITS 87-89 YZ125, YZ250 & 87-90 YZ490 | FITS 84-90 YZ490 40T-11111-00-00 | 1990 | YZ490 | FITS 84-90 YZ490, 92-93 WR500 | 1990 | YZ490 | FITS 84-90 YZ490 | 1990 | YZ490 | FITS 86-90 YZ125 YZ250 YZ490 - 1LX-21611-00-00 | 1990 | YZ490 | FITS 86-90 YZ490, 86 YZ125, 87 YZ250 | 1990 | YZ490 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1990 | YZ490 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | FITS 88-90 YZ490 | 1990 | YZ490 | LEFT 1LX-21711-01-98 - FITS 86-88 YZ125, 86-87 YZ250, 86-90 YZ490 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1990 | YZ490 | FITS 86-90 YZ490 & 92-93 WR500 | 1990 | YZ490 | |||||||||||||||||||||||||||
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
| 1992 | WR500 | FITS 91-92 YZ125 YZ250, 91-93 WR250, 92-93 WR500 | 1992 | WR500 | 1992 | WR500 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1992 | WR500 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1992 | WR500 | 1992 | WR500 | FITS 84-90 YZ490 & 92-93 WR500 | 1992 | WR500 | 43mm x 55mm x 9.5/10.5/11 | 1992 | WR500 | 1992 | WR500 | 1992 | WR500 | FITS 91 YZ250 WR250, 92-93 WR500 - 3XK-21511-00-00 | 1992 | WR500 | FITS 84-90 YZ490, 92-93 WR500 | 1992 | WR500 | 1992 | WR500 | FITS 91 YZ125 YZ250 WR250, 92 WR500 - 3XJ-21611-01-00 | 1992 | WR500 | 1992 | WR500 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1992 | WR500 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1992 | WR500 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1992 | WR500 | FITS 86-90 YZ490 & 92-93 WR500 | 1992 | WR500 | ||||||||||||||||||||||||||||||||||||||
| 1993 | WR500 | FITS 91-92 YZ125 YZ250, 91-93 WR250, 92-93 WR500 | 1993 | WR500 | 1993 | WR500 | FITS 83-86 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT 250, 83-84 IT490 -63T OD 148.65MM - 18T 52.65MM - Basket thickness 71.91MM - ID 32MM -16 Tines 13.92MM wide - 23X | 1993 | WR500 | FITS 83-86 YZ250, 84-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 39X-16150-00-00 | FITS 83-87 YZ250, 83-90 YZ490, 92-93 WR500, 83 IT250, 83-84 IT490, 85-86 YTZ250 23X-16351-00-00 | 1993 | WR500 | 1993 | WR500 | FITS 84-90 YZ490 & 92-93 WR500 | F8T206 FITS 83-90 YZ490, 92-83 WR500 | 1993 | WR500 | 43mm x 55mm x 9.5/10.5/11 | 1993 | WR500 | 1993 | WR500 | 1993 | WR500 | FITS 91 YZ250 WR250, 92-93 WR500 - 3XK-21511-00-00 | 1993 | WR500 | 1993 | WR500 | 1993 | WR500 | FITS 92 YZ125 YZ250, 92-93 WR250, 93 WR500 - 3XJ-21611-02-00 | 1993 | WR500 | 1993 | WR500 | FITS 86-90 YZ490, 92-93 WR500 | FITS 84-90 YZ490, 84-87 YZ250, 92-93 WR500 | 1993 | WR500 | FITS 80-87 YZ250, 80-81 YZ465 IT465, 81-83 IT250, 82 84-90 YZ490, 92-93 WR500 23X-18101-01-00 | 1993 | WR500 | FITS 86-97 YZ125 YZ250, 86-90 YZ490, 92-93 WR500, 97-97 WR250 - 1LX-22141-00-00 | 1993 | WR500 | FITS 86-90 YZ490 & 92-93 WR500 | 1993 | WR500 | ||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | ENGINE ID | AIR BOX | AIR BOX CAGE | AIR BOX TO CARB BOOT | ENGINE CASES | VIN FRAME USA ONLY | CABLE CLUTCH | CABLE FRONT BRAKE | YEAR | TYPE | CABLE THROTTLE | CARBURETOR | CARBURETOR BOOT (JOINT) (INSULATOR) INTAKE MANIFOLD | YEAR | TYPE | CDI | CLUTCH BASKET | YEAR | TYPE | CLUTCH HUB INNER | CLUTCH PRESSURE PLATE OUTER | YEAR | TYPE | COIL | CRANK SHAFT | CYLINDER | YEAR | TYPE | ENGINE MOUNTS LOWER | ENGINE MOUNTS UPPER | FLY WHEEL ROTOR | YEAR | TYPE | FORK INFO | FORK SEAL SIZES | FRONT AXLE | YEAR | TYPE | FRONT BRAKE BACKING PLATE | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT ENGINE MOUNTS | YEAR | TYPE | FRONT FENDER | FRONT HUB | HEAD | YEAR | TYPE | KICK LEVER SHAFT | petcock details | REAR AXLE | YEAR | TYPE | REAR BRAKE ARM (TENSION BAR) | REAR BRAKE BACKING PLATE | YEAR | TYPE | REAR HUB | REAR FENDER | YEAR | TYPE | SHOCK ARM LINKAGE | REAR WHEEL RIM | YEAR | TYPE | REED VALVE | SEAT | SHIFT FORKS | SHIFT LEVER | YEAR | TYPE | SHIFT SHAFT | SHOCK | YEAR | TYPE | SIDE COVER LEFT | SIDE COVER RIGHT | SWING ARM PIVOT PIN | THROTTLE CABLE | YEAR | TYPE | TRANSMISSION | TRIPLE TREE | YEAR | TYPE | SWING ARM |
